Hybrid Solar Kit 11.4KW 48V Split Phase 51.2 KWH Lithium Battery 36 X 450 Watt Solar Panel
Hybrid Solar Kit 51.2 KWH – In today’s world, the shift towards renewable energy sources is more significant than ever. One of the most effective solutions is the hybrid solar kit, which combines solar panels and battery storage to harness and store energy efficiently. With a capacity of 11.4 kW and a 48V split-phase configuration, the hybrid solar kit stands out as a powerful option for both residential and commercial use.
This Hybrid Solar Kit includes 16,200W of solar panels, a 2 X 11.4kW hybrid inverter, and 51.2KWh of lithium battery storage. The system supports flexible configurations—off-grid, hybrid, or grid-tied—enabling you to power appliances with solar energy, feed excess power back to the grid, and optionally store energy to offset bills or provide backup during outages.
Features of the 11.4 kW Solar Kit
This hybrid solar kit is equipped with a robust 51.2 kWh lithium battery, providing ample energy storage to meet varied power demands. The system comprises 36 x 450-watt solar panels that work in unison to capture sunlight and convert it into usable electricity.
This combination ensures high efficiency and reliability, making it an ideal choice for those looking to reduce their energy bills while minimising their carbon footprint.
What is included with the solar kits
- 2 X 11.4KW 48V Split Phase Hybrid Solar Inverter
- 36 X 450W Bifacial N-Type Monocrystalline Solar Panels
- 10 X 100AH 51.2V Lifepo4 Battery
- 2 X Enclosed Battery Cabinet for 10X 100AH 51.2V Lifepo4 Batteries
- 4 Sets X 50 Feet, Solar Extension Cables-Inverter PV input
- 2 X 2/0 AWG Battery Cable
- 4 X 25A PV Breakers
- 2 X 200A DC Breaker
Hybrid Solar Kit 51.2 KWH Specifications
1. Solar Kit 51.2 KWH Specifications
| Model Number | SGH-11N5E |
| AC Output | 11,400W |
| Output Waveform | Pure Sine Wave |
| AC Output | 120/240V(Split phase)/208V(2/3 phase)VAC |
| Max PV Input | 600VDC |
| Max.PV Input Power | 15,000W |
| Max Charging Current | 210A |
| Max.Input Current per MPPT | 30A/22A/22A |
| Nos. of MPPT | 3 |
| Dimension | 16.5 X 31.5 X 9.4inch |
| Weight | 88lb |
| Warranty | 10 Years |
| Certificates | UL1741/CSA,C22.2/UL1699B |
2. Battery Specifications
| Battery Model | SG48100P |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100AH |
| Energy | 5.12KWH |
| Charge cut-off current | 5A |
| MAX Continuous Charge Current | 100A |
| Discharge cut-off voltage | 43.2V |
| Cycle Life | ≥7000 |
| Communication Protocol | RS232/RS485/CAN Support multiple protocols |
| Storage Temperature | 14~+113°F |
| Dimension | 19.3 X 18.9 X 5.5 inch |
| Weight | 93lbs |
| Warranty | 10 Years |
| Certificates | UL1973, UL9540A |
3. Solar Panel Specifications
| Specification | Value |
| Peak Power | 450W |
| Cell Type | N-type Monocrystalline |
| Product Tolerance | ±3% |
| Maximum Power Current (IMP) | 14.97A |
| Maximum Power Voltage(VMP) | 30.08V |
| Short Circuit Current(ISC) | 16.05A |
| Open Circuit Voltage(VOC) | 35.03V |
| Product Dimension | 69.37 * 44.65 * 1.38 inch |
| Product Weight | 53.35 lbs |
| Material and workmanship warranty | 12 Years |
| Performance Warranty | 30 Years |
| Certificates | UL61730, CEC Listed |
Benefits of Using a Hybrid Solar Kit
Choosing a hybrid solar kit with 11.4 kW capacity not only enhances energy independence but also offers extended usability during outages.
The lithium battery’s longevity and performance ensure that homeowners or businesses can rely on a consistent energy supply. Furthermore, integrating this solar solution supports sustainability efforts, making a significant environmental impact.
In conclusion, investing in a hybrid solar kit with 51.2 kWh lithium battery and 36 x 450 watt solar panels positions owners to effectively utilise renewable energy, ensuring both economic and ecological benefits.
